GilgaMESH — Operator Manual

Image-to-mesh lane of the Livyatan Design Suite. Sovereign, local-first. PolyForm Small Business licensed (LICENSE.md).

Quickstart

trellis-make photo.png             # image -> printable STL
trellis-make "a garden gnome" 120  # words -> image -> STL, 120 mm tall

Either way you end with a watertight STL in ~/Desktop/bezier/ ready for the slicer. That's the whole interface — one command, one or two args.

What it is

A picture — or plain words — becomes a printable solid. The TRELLIS server on the GPU host reconstructs a textured GLB from the image, a converter scales it to your height in mm, and Blender voxel-remeshes it watertight. Photo in, solid out.

Features

• The chain: [FLUX paints, words-mode only] -> trellis-server (Vulkan trellis.cpp on the GPU host, :8080) -> textured GLB -> trellis_to_stl.py scales to height -> Blender voxel remesh -> watertight STL.
• Words mode: no file at arg 1 means it's a prompt; FLUX paints a single centered object on a plain background first (draft, no upscale — the mesh model resamples anyway).
• HEIGHT_MM: second arg, default 80. Sets the tallest dimension of the final STL.
• TRELLIS_HOST: env var — your GPU host. Point it wherever the server moves.
• Output: NAME.glb (textured mesh), NAME.stl (raw at height), NAME-watertight.stl (sliceable) — all in ~/Desktop/bezier/.
• Fail-loud: curl -sf (fixed 2026-08-15) — a server error stops the run naming the step; nothing is deleted on failure. No silent 500 written out as a .glb ever again.
• Lease-safe: the GPU job runs under the Styx lease, so it waits its turn instead of colliding with whatever else is holding the card. A model already resident stays resident.

Using it

trellis-make ~/Pictures/bracket.png        # photo of a thing, 80 mm
trellis-make part-sketch.jpg 45            # 45 mm tall
trellis-make "a socket organizer tray" 60  # no such file -> it's a prompt
TRELLIS_HOST=your-gpu-host trellis-make x.png   # different GPU host

Best input: one object, centered, plain background, decent light. The words path builds that framing into the prompt automatically. Watch the step tags ([flux], [trellis], [remesh]) — whichever prints last is where a failed run died. Deployed copy is ~/bin/trellis-make; keep it in sync with the repo copy.

How it connects

• GPU work runs on the GPU host under the Styx flock lease, beside the HADES-kept models — no collisions, no evictions.
• Downstream: the watertight STL feeds Jove (resin prep) and Hephaestus (CAM); the GLB views in Labyrinth.
• Words mode shares Phantasos's FLUX model stack — one paint pipeline, two consumers.

Known limits

• trellis-server must be up on the GPU host (:8080). Down server = loud stop at the [trellis] step.
• Reconstruction is minutes, not seconds. The 40-minute curl timeout is headroom, not a promise.
• Quality tracks the input photo: cluttered background, off-center subject, or bad light come back as mush. Fix the picture, not the mesh.

Queued

• Deeper suite integration (Nazca/Structor hand-offs).
• The trellis-server unit is not always-on yet — it may need starting on the GPU host before a run.
